Teryl® edged tape
Construction :
- Woven tapes with 100% Polyester yarn in wrap and weft, (continuous yarns). heat shrinkable.
Type of weaving :
- LINEN : Perpendicular weaving, wrap and weft. For a similar thickness, the linen weaving makes a tape with more holding, but less supple than serge weaving.
- SERGE : Herringbone weaving. It allows to have a tape which can bend out of shape slightly more easily than a linen woven tape, it better gets into its position in low radius bends.
Thermo shrinkage :
2 types : with no charge. Under charge. In the board of reference, we have indicated :
LOW MEDIUM HIGH
(< 5%) (≥ 5% < 10%) (≥ 10%)
NB : Please see the data sheet.PDF for the details.
| Product | Thickness | Weaving | Shrinkage at 140°C | Width | Unit | Selection |
|---|---|---|---|---|---|---|
| T 017 | 0.13 mm | Toile - linen | Moyenne - Medium | 10 à 60 mm | M | |
| T 011 | 0.13 mm | Toile - Linen | Forte - High | 10 à 50 mm | M | |
| T 139 | 0.16 mm | Toile - Linen | Forte - High | 10 à 50 mm | M | |
| T 016 | 0.20 mm | Sergé - Twill | Faible - Low | 10 à 50 mm | M | |
| T 019 | 0.25 mm | Sergé - Twill | Forte - High | 10 à 50 mm | M | |
| T 014 | 0.40 mm | Sergé - Twill | Forte - High | 20 à 50 mm | M | |
| T 017 | 0.13 mm | Toile - Linen | Moyenne - Medium | 10 à 50 mm | M | |
| T 014 | 0.40 mm | Sergé - Twill | Forte - High | 10 à 50 mm | M |
